Topology

Last Updated : Nov 06, 2023 |

The following diagram depicts the architecture for the deployment of a typical Avaya Workspaces for Call Center Elite solution with a maximum capacity of 1000 agents.

Figure : 1. Topology - small solution




The following diagram depicts the architecture for the deployment of a typical Avaya Workspaces for Call Center Elite solution with a maximum capacity of 7500 agents.

Figure : 2. Topology - large solution
